COMP Cams Valve Spring Ford 4-6L 2 Valve

With a .550" maximum lift, these Beehive Valve Springs were designed for Ford 4.6L and 5.4L Modular 2 and 3 Valve engines. COMP Cams Beehive Valve Springs deliver increased valve train stability and a much lighter valve train. This is achieved with less spring pressure for better valve control and reduced weight of both the spring and retainer. The unique Beehive shape handles valve train stress more efficiently to eliminate damaging harmonics and increases high RPM horsepower and durability. The oval/multi-arc wire shape places the maximum area of the wire at the point of highest stress to handle valve train stress more efficiently and allow better heat dissipation for longer life. Because of the unique Beehive design, the valve train can handle more RPM and more aggressive cam profiles.

.959"/1.061" OD, .636"/.738" ID Beehive valve spring for Modular Ford; 93 lbs 1.570", 198 lbs 1.020"; Designed for Ford 4.6L Modular 4 Valve engines

Valve Springs; Dual Valve Springs; Single Valve Springs; Beehive Springs; Conical Springs; Valve Lift; Max Lift; Spring Kit

COMP Cams Beehive Valve Spring for Ford Modular Engines, .959"/1.061" OD, 93 lbs 1.570", 198 lbs 1.020"

Performance Street 1.061" OD Beehive Spring; 1.570" Installed Height; 1 Spring

COMP Cams Valve Spring Ford 4.6L 2 Valve

Perf St 1.061" Beehive 1.570" Inst Ht

Valve Spring, Ford 4.6L 2 Valve SOHC

Engine Valve Spring
